Sinusoidal Profile Sheet is a part of corrugated profile family featuring a profile which is shallow. These roofing sheets are used mainly as a roof, which are relatively steep & the purlins are closely spaced. These sheets look very elegant as roof because it has very smooth curves. One cannot walk on these Sinusoidal and Trapezoidal profiles, as it is not made for foot traffic. For right profile according to your requirements, you can contact us.
We manufacture and supply Sinusoidal roofing sheets, Trapezoidal profiles, Sinusoidal S-Profile all over Dubai, Sharjah, Ajman, Abu Dhabi, Ras Al-Khaimah, Al’Ain, Fujairah.
Sinusoidal and trapezoidal profiles curved cladding dimension
GlobeMetalsUAE mainly produce and supply ‘Smooth Curve’ & ‘Site Curve’ type of curved sheets all over the Middle East.
Thickness: 0.35 mm to 1.5 mm x width 1000 mm x Length (As per our customer’s choice)
Grade ASTM A653 as Galvanized Steel with high Zinc coating
Aluminium ASTM B209 Mill finish and color as requested
Corrugation 18/76 mm
Handling of Sinusoidal corrugated sheeting on site
In comparison with other sheets, sinusoidal corrugated sheets are lightweight and strong, thus making it easier and less time-consuming to handle long sheets also they are sustainable and economical.
Fixing of Sinusoidal Profile Sheet
The right way to fix these sheets is to drill a hole through the sheet and with the help of self-tapping or drilling screws fix the roofing sheet to the purlins. To further strengthen the fix, the washer should be tightly fastened through a steel or aluminium saddle washer, which can be colour of your choice. After the fastening, the fixing area can be covered by a same colour PVC cap. The distance of the profile crown should not be more than 153 mm. Sinusoidal sheet are best for wall cladding. Sinusoidal corrugated sheeting ideal for finished roof pitches which are greater than 4°, and which can be curved to get outstanding architectural designs.
GlobeMetalsUAE, is the leading manufacturer & supplier of sinusoidal sheet for wall cladding and well as sinusoidal profile sheet all over Dubai, Sharjah, Ajman, Abu Dhabi, Ras Al-Khaimah, Al’Ain, Fujairah and also provides all required accessories for roofing metals at the best price. We also export these roofing sheets and metal all over Oman (Salalah, Muscat, Sohar, Nizwa, Barka, Ibri) | Saudi | Iraq | Kuwait | Bahrain | Sri Lanka.
Side Lap Fixing
These should normally have an extra half-lap on each corrugation side, be sealed with a strip sealant, and riveted at 300-400 mm centres, depending on the pitch of the roof. Although rivets are required in vertical circumstances or roof pitches more than 15°, the sealant strip can be removed.
End Lap Fixing
End laps vary in size depending on the roof pitch, but a minimum of 150 mm is suggested.
Contact Sinusoidal Profile Sheet Near You
IF you search sinusoidal profile sheet near me in Google.ae, chances are that you will find our company GlobeMetalsUAE.com or GhoshGroups.com on top of the list as we are the leading manufacturer & supplier of all types of roofing sheets supplies in the Middle East.
And if you want to contact our expert, you can Call / WhatsApp on +971 503 034 002 and detailed information can be provided, if you email on parimal@ghoshgroups.com
